Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery

Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery
Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery
Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery
Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery
Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery
Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery

Hanxingcn XINGXI-L Series 5~30 kWh Low Voltage LFP Battery

Hanxingcn XINGXI-L Series Low Voltage Battery Systems are great for off-grid systems, and users looking for large capacity potential with a medium to low energy demand.

  • Brand:

    HANXINGCN
  • Order(MOQ):

    1
  • Payment:

    T/T, L/C, Western Union
  • LeadTime:

    30 days
  • Battery Type:

    LFP
  • Nominal Capacity:

    5.12 kWh / 10.24 kWh / 15.36 kWh / 20.48 kWh / 25.6 kWh / 30.72 kWh
  • Nominal Voltage:

    51.2V

XINGXI-L Series 5~30 kWh Low Voltage LFP Battery



Product Description



Hanxingcn XINGXI-L series is a lithium-ion battery specifically designed for residential use in low-voltage battery systems. Its purpose is to assist homeowners in maximizing the utilization of solar energy and minimizing energy expenses. The XINGXI-L series offers effortless installation with its plug-and-play feature, facilitated by pre-wired communication cables. Notably, it allows for flexible scaling from 5.12 to 92.16 kWh, and its self-detecting modules and stackable design simplify the commissioning process for installers.



XINGXI-L series low voltage LiFePO4 battery starts at 5.12 kWh with each additional module offering an extra 5.12kWh. It can be combined with various single-phase inverters and most photovoltaic system. Ideal for your residential solar and battery system.




Features



  •   Maximum flexibility for any application with up to 18 Modules connected in parallel
  •   Capable of off-grid function
  •   6000 cycle life
  •   Compatible with inverters such as GROWATT, Solid, invt, etc
  •   Floor Mounted







Technical Parameter



  XINGXI-5-L XINGXI-10-L XINGXI-15-L XINGXI-20-L XINGXI-25-L XINGXI-30-L
Nominal Capacity 5.12 kWh 10.24 kWh 15.36 kWh 20.48 kWh 25.6 kWh 30.72 kWh
Usable Capacity 4.608 kWh 9.216 kWh 13.824 kWh 18.432 kWh 23.04 kWh 27.648 kWh
Battery Type LFP 100Ah
Rated Charging / Discharging Current 66 A 97 A 97 A 97 A 97 A 97 A
Weight 44 kg 82 kg 120 kg 152 kg 190 kg 222 kg
Dimensions (W*D*H) 700*460*381 mm
700*460*698 mm
700*460*1015 mm
700*460*1332 mm 700*460*1649 mm 700*460*1996 mm
Nominal Voltage 51.2 V
Operating Voltage 48 V ~ 57.6 V
Operating Temperature
Charge: 0℃ to 50℃ / Discharge: -10℃ to 50℃
Short-circuit Current 2.323kA @ 1.0ms
Communication CAN/RS485
Relative Humidity 0~95%
Max. Operating Altitude 2000 m
Enclosure Protection Rating IP54
Mounting Method Floor stand
Certification TÜV SÜD / CE / UN38.3 / MSDS
